quick release hinge
Electrical box hinge assembly kits are ideal for NEMA and JIC enclosures.
Kit includes quick release pin which is also sold separately as part number X127-03.
For a proper seal between leaf, box and bracket, the through holes on the electrical box must be .234″-.236″ diameter.
All components can be purchased separately.
Leaves, screws and pin are made from mill finished stainless steel.
Utility bracket is made from zinc plated steel and sealing washer is smooth nylon.
Additional Information 1
| Weight | 0.152 lbs |
|---|---|
| Material | 304 Stainless Steel |
| Finish | Mill |
| Type | |
| Industry | Enclosures/Electrical Enclosures, Enclosures/Switchgear |
