continuous hinge for nema / jic enclosure cabinet
- Continuous hinges for enclosure cabinets are made from aluminum.
- Hinges have (1) 1.00" leaf and (1) formed .77" leaf.
- Hinge is 72.00" long, 0.072" thick with no mounting holes.
- 1.00" leaf has a .031" offset.
- Aluminum pin has a 0.250" diameter.
Additional Information 1
| Weight | 2.61 lbs |
|---|---|
| Material | Aluminum |
| Finish | Mill |
| Type | |
| Industry | Enclosures/Electrical Enclosures, Enclosures/Switchgear |
- Continuous hinges for enclosure cabinets are made from aluminum.
- Hinges have (1) 1.00" leaf and (1) formed .77" leaf.
- Hinge is 72.00" long, 0.072" thick with no mounting holes.
- 1.00" leaf has a .031" offset.
- Aluminum pin has a 0.250" diameter.
